Short Description
10hp Screw Compressor plant offers 10hp Screw Compressor, SSC12710, 270ltr, 1550 x 590 x 1255mm, 217kg, 145psi(10bar), 3ph Low Noise.
 |
Previous: Vertical 200ltr Tank Compressor, SA200T
Next: Retractable Air Hose Reel, SA93, 10mm ID, 20mtr, 300psi
Next: Retractable Air Hose Reel, SA93, 10mm ID, 20mtr, 300psi
10hp Screw Compressor, SSC12710, 270ltr, 3ph Key Specifications / Features
Model No: SSC12710
Motor Output: 10hp
Voltage/Phase: 415V - 3ph
Minimum Rated Supply: 32A
Noise Level: 67dB(A)
Maximum Free Air Delivery cfm(ltr/min): 30.2(860)
Maximum Pressure: 145psi(10bar)
Receiver Capacity: 270ltr
Dimensions (W x D x H): 1550 x 590 x 1255mm
Weight: 217kg
High performance, top of the range screw compressors offer high continuous output of air with low running costs.
One of the most economical ways to get compressed air 24/7 with minimal downtime.
Very few moving parts, means servicing/maintenance will be less frequent and less expensive compared to an equivalent piston model.
Insulated Class F 10hp motor with IP54 protected control box, which is easy to operate with digital display showing key information like air pressure, oil temperature and maintenance schedules.
Features an insulated outer casing to minimize noise (67dB(A) at 1mtr) and offers protection to inner components.
Also fitted with a drain valve tap at base of unit to ensure easy function tank drain when required.
Motor Output: 10hp
Voltage/Phase: 415V - 3ph
Minimum Rated Supply: 32A
Noise Level: 67dB(A)
Maximum Free Air Delivery cfm(ltr/min): 30.2(860)
Maximum Pressure: 145psi(10bar)
Receiver Capacity: 270ltr
Dimensions (W x D x H): 1550 x 590 x 1255mm
Weight: 217kg
High performance, top of the range screw compressors offer high continuous output of air with low running costs.
One of the most economical ways to get compressed air 24/7 with minimal downtime.
Very few moving parts, means servicing/maintenance will be less frequent and less expensive compared to an equivalent piston model.
Insulated Class F 10hp motor with IP54 protected control box, which is easy to operate with digital display showing key information like air pressure, oil temperature and maintenance schedules.
Features an insulated outer casing to minimize noise (67dB(A) at 1mtr) and offers protection to inner components.
Also fitted with a drain valve tap at base of unit to ensure easy function tank drain when required.
