Short Description
Belt Drive 2hp Compressor Company Honest offers Belt Drive 2hp Compressor, SAC05020, 50ltr, 380 x 400 x 875mm, 23kg, 145psi(10bar), Oil Free.
 |
Previous: Direct Drive 2hp Compressor, SA2420, 24ltr, 25kg
Next: Vertical 200ltr Tank Compressor, SA200T
Next: Vertical 200ltr Tank Compressor, SA200T
Belt Drive 2hp Compressor, SAC05020, 50ltr, Oil Free Key Specifications / Features
Model No: SAC05020
Motor Output: 2hp
Voltage/Phase: 230V - 1ph
Minimum Rated Supply: 13A
Air Displacement cfm(ltr/min): 7.3(205)
Maximum Free Air Delivery cfm(ltr/min): 5.1(145)
Maximum Pressure: 145psi(10bar)
Receiver Capacity: 50ltr
Dimensions (W x D x H): 380 x 400 x 875mm
Weight: 23kg
Aluminium cylinder with cast iron lining gives reduced weight and improved resistance to wear.
Suitable for general purpose workshop applications.
Oil free, single piston pump is belt driven by a 2hp motor and fixed to a vertical type tank, saving space around the workshop.
Precision welded receiver tank manufactured to meet Pressure Vessel Directive.
Fitted with fully automatic pressure cut-out switch and air regulator with gauge.
Supplied with handle and wheels for easy manoeuvrability.
Fitted with ASTA/BS approved non-rewirable plug.
Motor Output: 2hp
Voltage/Phase: 230V - 1ph
Minimum Rated Supply: 13A
Air Displacement cfm(ltr/min): 7.3(205)
Maximum Free Air Delivery cfm(ltr/min): 5.1(145)
Maximum Pressure: 145psi(10bar)
Receiver Capacity: 50ltr
Dimensions (W x D x H): 380 x 400 x 875mm
Weight: 23kg
Aluminium cylinder with cast iron lining gives reduced weight and improved resistance to wear.
Suitable for general purpose workshop applications.
Oil free, single piston pump is belt driven by a 2hp motor and fixed to a vertical type tank, saving space around the workshop.
Precision welded receiver tank manufactured to meet Pressure Vessel Directive.
Fitted with fully automatic pressure cut-out switch and air regulator with gauge.
Supplied with handle and wheels for easy manoeuvrability.
Fitted with ASTA/BS approved non-rewirable plug.
