Short Description
Direct Drive 2hp Compressor Manufacturer Honest supplies Direct Drive 2hp Compressor，SA2420，24ltr，25kg, 620 x 330 x 610mm, 116psi(8bar).
 |
Direct Drive 2hp Compressor, SA2420, 24ltr, 25kg Key Specifications / Features
Model No: SA2420
Motor Output: 2hp
Voltage/Phase: 230V - 1ph
Minimum Rated Supply: 13A
Air Displacement cfm(ltr/min): 6.7(190)
Maximum Free Air Delivery cfm(ltr/min): 4.7(133)
Maximum Pressure: 116psi(8bar)
Receiver Capacity: 24ltr
Dimensions (W x D x H): 620 x 330 x 610mm
Weight: 25kg
Aluminium head with cast iron cylinder gives added resistance to wear.
Suitable for general purpose workshop applications.
Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
Welded tank complies with latest European standards.
Fitted with fully automatic pressure cut-out switch with twin gauges displaying tank and working pressures.
Fitted with ASTA/BS approved non-rewirable plug.
Motor Output: 2hp
Voltage/Phase: 230V - 1ph
Minimum Rated Supply: 13A
Air Displacement cfm(ltr/min): 6.7(190)
Maximum Free Air Delivery cfm(ltr/min): 4.7(133)
Maximum Pressure: 116psi(8bar)
Receiver Capacity: 24ltr
Dimensions (W x D x H): 620 x 330 x 610mm
Weight: 25kg
Aluminium head with cast iron cylinder gives added resistance to wear.
Suitable for general purpose workshop applications.
Pump head directly coupled to heavy-duty induction motor for reliable and quiet operation.
Welded tank complies with latest European standards.
Fitted with fully automatic pressure cut-out switch with twin gauges displaying tank and working pressures.
Fitted with ASTA/BS approved non-rewirable plug.
