Short Description
Spot Welder dealer Honest offers Spot Welder with Digital Timer: SR123, Welding Current (Max) 6300A, Supply 230V, Power 13kW, with Digital Timer.
 |
Spot Welder with Digital Timer, SR123, 230V, 13kW Key Specifications / Features
Model No: SR123
Supply: 230V
Capacity: 2 + 2mm
Maximum Absorbed Power: 13kW
Mains Fuse: 25A
Welding Current (Maximum): 6300A
Duty Cycle: 1.5%
Insulation Class：B
Weight: 11kg
Semi-automatic spot welder.
Integral electronic control allows operator to select thickness of material while automatically calculating the optimum weld duration.
Also features pulse mode for use on high stress steels commonly found in modern vehicle construction.
All automatically selected parameters may be overridden by the operator if required.
Composite casing and handle reduce heat transfer for operator comfort.
Die-cast aluminium head and chassis reduces overall weight for improved handling.
Fully adjustable jaw pressure from 40kg to 120kg enables close control of weld quality.
Supplied with 120mm welding arms, electrodes and side handle.
Made in Europe.
Supply: 230V
Capacity: 2 + 2mm
Maximum Absorbed Power: 13kW
Mains Fuse: 25A
Welding Current (Maximum): 6300A
Duty Cycle: 1.5%
Insulation Class：B
Weight: 11kg
Semi-automatic spot welder.
Integral electronic control allows operator to select thickness of material while automatically calculating the optimum weld duration.
Also features pulse mode for use on high stress steels commonly found in modern vehicle construction.
All automatically selected parameters may be overridden by the operator if required.
Composite casing and handle reduce heat transfer for operator comfort.
Die-cast aluminium head and chassis reduces overall weight for improved handling.
Fully adjustable jaw pressure from 40kg to 120kg enables close control of weld quality.
Supplied with 120mm welding arms, electrodes and side handle.
Made in Europe.
